SURE-FLOAT Floating Regulator from Grande

The SURE-FLOAT Floating Regulator maintains a constant flow rate, ranging from 80 gpm (5 L/s) to 480 gpm (30 L/s), regardless of upstream water levels. Actually, this system is ideal for use in settling ponds, tailings ponds, stormwater retention tanks, and other applications where precise flow control is needed. Overall, the SURE-FLOAT operates without the need for electrical connections or a separate structure, making it a cost-effective and reliable solution for regulating small discharges.

Key Features of the SURE-FLOAT Floating Regulator

• Wide Flow Range: Regulates flows from 80 gpm to 480 gpm, covering various application needs.
• Waterhead Up to 20 ft (6 m): Ideal for environments with varying water levels.
• No Electrical Connection Required: Operates passively, reducing setup and maintenance costs.
• Adjustable Flow Rate: Easily adjustable on-site by adding or removing water from the floats.
• Easy Installation: Designed for easy adaptation to existing installations.
• Durable Construction: Built with stainless steel, ensuring long-lasting reliability and resistance to harsh environments.
• Cost-Effective: No need for a separate structure or ground inversion offset.

How the SURE-FLOAT Floating Regulator Works

The SURE-FLOAT system operates by maintaining the inlet opening in a horizontal position, optimizing flow control. The system uses floating floats to control the submergence of the inlet, ensuring consistent flow. The integrated deflector and weir separate solids without impacting flow. If needed, the deflector can be removed for a skimming function.

Each SURE-FLOAT unit is pre-set to the desired flow rate and can be adjusted on-site by adding or removing water from the floats. The system requires no costly on-site calibration, making installation quick and easy.

Nulantic Water proudly represents SURE-FLOAT Floating Regulator from Grande throughout Atlantic Canada. What is more, we offer advanced water management solutions that improve overflow control and water quality. Our focus on reducing water pollution and maximizing storage capacity ensures reliable, cost-effective solutions for local industries and municipalities.
